Name: CK-OBDProg OBD Hardware + Odometer Adjustment Function Activation



Description:



CK-OBDProg is a vehicle diagnostic device that draws power from the OBD diagnostic connector and communicates with a phone over Bluetooth Low Energy(BLE). Used with the HUIDAO CK APP, it performs two tasks: reading immobilizer data and completing key programming, and reading, modifying and writing the internal data of the instrument cluster for instrument data repair.



CK OBDProg OBD Hardware has no operable buttons and no display. All interaction takes place in the APP. Protocol handling runs on the chip inside the device, which supports multiple communication protocols including CAN, CAN FD and DoIP. The APP handles model selection, parameter entry and result display. Part of the immobilizer data is computed on the server, so the phone needs to stay online during the job.



Functions:



1. OBD Key Programming

1). Generate OBD for programming from the model, model year and key type(mechanical key, remote control or smart key).

2). Read internal data from the immobilizer control unit (IMMO / BCM / CAS and similar).

3). Read the number and status of registered keys.

4). Add keys, and reprogram after all keys are lost.

5). Learn remote controls and smart keys (PEPS).

6). Back up and restore immobilizer data.



2. Instrument Data Repair

1). Read instrument memory data (EEPROM / MCU data area).

2). Back up, modify and write data.

3). Repair needle zero position and display segment faults.



3. Odometer Adjustment

Odometer Adjustment refers to the technical process of modifying or calibrating the mileage value displayed on a vehicle's instrument cluster. In a legitimate context, it is performed to correct or replace a faulty odometer so that the new reading accurately reflects the vehicle's actual accumulated mileage, or to document changes when a replacement cluster cannot retain the original figure.



Supported Cars：



The device covers mainstream brands and vehicle families, including but not limited to the brands listed below. Support for specific models, model years and trim levels follows the model library that is updated live inside the HUIDAO CK APP.



German:

Volkswagen, Audi, BMW, Mercedes-Benz, Porsche, Skoda, Opel



Japanese:

Toyota, Honda, Nissan, Mazda, Mitsubishi, Subaru, Suzuki, Lexus, Infiniti, Acura



American:

Ford, Chevrolet, Buick, Cadillac, Chrysler, Jeep, Dodge, Lincoln, GMC



Korean:

Hyundai, Kia, SsangYong



French:

Peugeot, Citroen, Renault



Chinese:

BYD, Geely, Changan, Great Wall (Haval / WEY), Chery, Roewe, GAC Trumpchi, FAW Besturn, Dongfeng Aeolus, Wuling Baojun, Hongqi, Lynk and Co, NIO, XPeng, Li Auto



Note:



Brand coverage does not mean full model and trim coverage. Certain newly launched models, immobilizer systems with a high encryption level, and vehicles that rely on online programming require network authorization or dedicated adapters. Follow the prompts in the APP.



APP Download and Install Instructions:



Android:

Search for HUIDAO CK in APP market, or scan the QR code on the package.



iOS:

Search for HUIDAO CK on the App Store iOS 13.0 or later



Note:



Once installed, simply follow the prompts in the APP. After the connection succeeds, the APP automatically jumps to the OBD operation screen; to use a different phone, just connect the same device again.



Specifications:



Interface: OBD-II 16-pin standard diagnostic connector

Operating Voltage: DC 9V to 16V (supplied by the vehicle OBD2 socket)

Operating Current: 120 to 200mA (12V power supply)

Wireless: Bluetooth low energy 5.0, range 3 meter

Operating Temperature: -20°C to +70°C

Storage Temperature: -40°C to +85°C

Expansion Ports: MCU read/write adapter interface on the rear (double-row pin header); 2 USB Type-C ports on the tail (left: RFID adapter, right: power supply)

Communication Protocols: CAN (ISO 15765); K-line (ISO 9141, KWP2000); CAN FD (ISO11898-1); DoIP (ISO 13400)
